AC 3500
Wall Mounted Type DC Solar Air-Conditioner
Description
| SPECIFICATION | |||
| Wall Mounted Type DC Solar Air-Conditioner(4 hours) | |||
| Power Supply: 48VDC (44V to 54V) | |||
| Model No. | AC3500 | ||
| Performance | |||
| Capacity | Cooling | Btu/h | 12000 |
| W | 3500 | ||
| heating | Btu/h | 13000 | |
| W | 3700 | ||
| Noise | Indoor | dB(A) | ≤42 |
| Outdoor | dB(A) | ≤52 | |
| Air Circulation | m³/h | 550 | |
| Suitable Area | m² | 12~25 | |
| EER | W/W | 3.89 | |
| Btu/h/w | 13.33 | ||
| Batteries | 12V x 4pcs | ||
| Battery AH(each) | AH | 100 | |
| Solar panel specification | 150W x 6pcs | ||
| Charge Controller | 45A/48V | ||
| Refrigerant | R-410A | ||
| Compressor | DC 48V | ||
| Power Consumption | |||
| Power Input | W | 900 | |
| Rated Current | A | 16 | |
| Input Power | V | DC 48 | |
