SWH 125

Non Pressurized Solar Water Heater



SWH 125

Non Pressurized Solar Water Heater

Model SWH 125
Tank Capacity 100L
Tube Capacity 26L
Total Capacity 126L
Inner Tank Material Stainless Steel SUS304-2B
Thickness 0.5mm
Diameter 380mm
Outer Tank Material Whiter Painted Steel
Diameter 472mm
Thickness 0.4mm
Side Cover Sky Blue Side Cover
Insulation Polyurethane,high-pressure foaming,50mm
Connector Diameter 3/4″
Type 58/1800mm,Three-Target high efficent vacuum tube
Tube Quantity 10 pieces
Material Aluminum Alloy 6063
Stand Thickness 1.5mm
Inclination 30 Degree
Reflector No Reflector
Other Parts Anod Protection Included(Designed-In With Tank)
Electric Heater Optional, Not Included
Digital Controller Optional, Not Included
Container 20GP/40GP/40HC
